8.2 x 3.5m Springfield Pro System flat roof Summerhouse
This garden summerhouse is made using the Lugarde "Pro System" - which is a modular system of construction using different standard elements in order to make numerous different combinations of design of building.
This design is for a 3.5x3.5m summerhouse with a covered seating area to one side.
All Lugarde models are delivered with double glazing in the windows and doors
Pressure treated floor bearers
The roof looks flat from around the edges, but it is in fact a sloping deck within the fascia boards to avoid water build-up, which in turn flows into an integral downpipe.
The EPDM roofing material consists of a rubber mat, edged with an aluminium strip on all sides
Chrome or brass metalwork
View installation videos for this summer house -
click here
-
Cabin width: 8.2m
-
Cabin depth: 3.5m
-
Wall logs: 44mm
-
Wall heights: 2.21m
-
Over all height (including fascia boards): 2.49m
-
Double glazed sliding patio doors SD200 x 1
-
Double glazed fixed windows PJ07 x 2
