The Cheam Pavilion - 11m x 5.5m single skin


Starting at: £27,677.83

Please Choose:

I want to modify the size/design of this building




Upgrade doors and windows (all with toughened glass)











Black hexagonal

Green hexagonal

Red hexagonal

Black square

Red square

Recycled rubber roofing slates (50 year manufacturers warranty)




Upgrade your log cabin with uPVC windows and doors

Not available for 28mm single skin cabins. Doors have toughened glass as standard







uPVC handle and hinge colour









Extra partition walling (extra charges will apply if factory painting and/or installation is also required)





Timber base kit




Weed and damp-proof membranes





Roof & floor insulation kit for single skin cabin





Guttering

NB - if you choose water butts please bear in mind that you will also need an extra hard standing area - they cannot be installed onto grass or dirt









Fire protection coating Class B - s1,d0 (ie better than UK Building regulations Class 0)





Factory painting - timber is planed, not sanded before treatment is applied

(NB you will need to order extra tins of paint if you intend to paint your ceiling/roof overhangs/canopies to match the walls)









Please type your colour choice from the Teknos colour chart in the text box




Please choose if you have opted for Remmers factory or self applied




Sadolin Classic & Remmers = translucent, Superdec = semi-opaque - enough in tins for 2 coats to the external walls




Please choose if you have opted for self applied Sadolin







Gold star base coat (self-application)





Discount paints deal! Big savings - save over 15%!

Sale price - discounts available with our paints and timber treatments bundle





Cabin images on our website may also show optional extras (roof coverings, verandas etc). The paint colour images on our website may vary to the colour of treatment you purchase. You should try a sample pot first - paints & stains are non-returnable.

All surfaces (internal and external) of your log cabin must be painted with an appropriate timber treatment or sealer


Installation service for log cabins and timber buildings









Other items that you may want to enquire about




There are many variables involved in building large log cabins or timber framed buildings. We can quote once the final design and specification has been decided (ie. Factory painting)

Installation service for large timber buildings





Cheam Pavilion Specification

Log Cabin Dimensions

  • Wall log thickness : 70 mm
  • 11.0m overall pavilion width
  • 5.5m overall pavilion depth including verandah area
  • Minimum base width required : 10.8 m
  • Minimum base depth required : 5.3 m
  • Wall height : 2.4 m
  • Ridge height : 3.5 m
  • T&G roof board thickness : 19 mm
  • T&G floor board thickness : 28mm

Also Included With This Pavilion

  • House quality, tilt & turn, multipoint locking, double glazed double windows with toughened glass 1365x980mm : 4
  • House quality, multipoint locking, double glazed double doors, half glazed with toughened glass 2100x1565mm : 1
  • House quality, multipoint locking, single door, fully boarded 2100x1050mm : 1
  • Tanalised floor bearers : included
  • Internal archways : supplied
  • Roof shingles : supplied (choice of colours and shapes)
  • Full width x 1.5m deep verandah with decking and balustrading
This sports pavilion log cabin is one large space inside - made possible by the use of 2 archways which support the roof structure. It can be made to various sizes and configurations to meet your requirements, with or without internal partitions, making it very adaptable. It can be used for a classroom, pavilion, clubhouse, village hall etc.
The specification above is for a single skin wall construction, but if the pavilion will be heated using permanent wall heaters or similar, then it will generally have to comply with building regulations for insulation, we are able to achieve this by using our twinskin, cavity wall specification (see separate twinskin listing for details).
  • Model: 9232-11055-70
  • Manufactured by: Hortons
