38 sq m log house with mezzanine floor 60-60mm logs


Starting at: £17,487.20

Please Choose:

I want to modify the size/design of this building




Change roof style option






Felt Shingles (self bonding and fibre reinforced for expected lifespan of 30 years)






Black hexagonal

Green hexagonal

Red hexagonal

Black square

Red square

EPDM rubber roofing, easy self-installation




Recycled rubber roofing slates (50 year manufacturers warranty)




Base For Log Cabin




Twinskin insulation kit (thickness for each element shown in brackets)






Floor Upgrade








(NB you will need to order extra paint if you intend to paint your roof overhangs/canopies to match the walls)

Factory painting- timber is planed, not sanded before treatment is applied








Sadolin Classic / Superdec / Remmers (self application) - long lasting protection

Sadolin Classic & Remmers = translucent, Superdec = semi-opaque - supplied in tins, enough for 2 coats externally





Sadolin colour required





Stone pine

Teak

Mahogany

Nutwood


Chestnut

Palisander

Rustic oak

Light oak


Hemlock

Frisian blue

Salt green

Fir green


White

Silver grey

Clay grey

Window grey


Tuscany grey

Graphite grey

Sand grey

Mist grey


Platinum grey

Water grey

Anthracite grey

Granite grey


Ebony

Gold star base coat (self-application)




Cabin images on our website may also show optional extras (roof coverings, verandas etc). The paint colours represented on our website may not be an exact match to the colour of timber treatment you purchase. If in doubt, try a sample pot first

All surfaces (internal ans external) of your log cabin must be painted with an appropriate timber treatment or sealer


Installation service for large timber buildings

There are many variable involved in building large log cabins or timber framed buildings. We can quote once the final design and specification has been decided







Twinskin Cabin with dwelling house quality windows and doors
This cabin comes with:



  • Insulation cavities can be filled with Fibreglass/Celotex/Kingspan within floor, roof and walls
  • roofing felt shingles
  • fixing kit
  • storage / sleeping area in mezzanine floor above two small rooms
  • All doors and windows are "ISO" house quality and supplied with handles and multi-point locking system


External wall 60mm
Insulation cavity 100mm
Internal wall 60mm
Size metres: 5.00 x 5.00
Veranda depth in metres: 1.80
Roof canopy in metres: 1.80
Internal partition: supplied
Mezzanine floor: supplied
Eaves height metres: 2.3
Ridge Height metres: 3.80
T&G Roof boards millimetres: 19
T&G Floor boards millimetres: 19
JOINERY
To obtain compliance with Building Regulations with Double glazing it is necessary to use wide cavities of 12mm to 16mm making overall thickness of 20mm to 24mm. We are using 16mm wide cavities and overall 24mm double glazed units filled with an inert insulating gas.
1 x Glulam timber frame tilt and turn single window 600x600mm, with espagnolette, glazed with 4/16/4mm double glazed units filled with an inert insulating gas
1 x Glulam timber frame tilt and turn single window 980x710mm, with espagnolette, glazed with 4/16/4mm double glazed units filled with an inert insulating gas
2 x Glulam timber frame tilt and turn double windows 980x1365mm, with espagnolette, glazed with 4/16/4mm double glazed units filled with an inert insulating gas
1 x Glulam timber frame double doors 1855x1565mm with espagnolette furnishings, euro lock which has a deadlocking facility, half glazed with 4/16/4mm double glazed units filled with an inert insulating gas
2 x Single internal doors, fully boarded 1855x850mm

  • Model: 9085-5058-6060-16S
